Cavendish Labs, Energy Efficient Air Handling

Sector – Air Handling Units

With supplier sustainability and technical expertise being key partnership drivers, Mansfield Pollard were engaged by main contractor Bouygues UK to design, manufacture and install air handling units, serving all areas of the 33,000m2 development and contribute to the delivery of a BREEAM rating of EXCELLENT for the full development.

Download the full case study

Partnership Approach

With supplier sustainability and technical expertise being key partnership drivers, Mansfield Pollard were engaged by main contractor Bouygues UK to design, manufacture and install air handling units, serving all areas of the 33,000m2 development and contribute to the delivery of a BREEAM rating of EXCELLENT for the full development.

Cavendish Laboratories

Cavendish laboratories have been home to the Department of Physics since 1874. The 250 million redevelopment has provided a purpose-built centre for world-leading research, bringing together all of the Cavendish’s research groups under one roof. The flagship building is the Ray Dolby Centre, in recognition of a 75 million gift from the estate of sound pioneer Ray Dolby.

With a gross internal area of around 354,000 sq ft (33,000 sq m), the Ray Dolby Centre will house a range of laboratories, offices, clean rooms, workshops and multiple lecture theatres. An independent 50,000 sq ft (4,700 sq m) shared facilities hub will provide catering, collaborative teaching, meeting, study and library spaces to the campus.

The Highlights

Twenty precision air handling units were required to provide critical ventilation to all areas of the new Cavendish Laboratories redevelopment. All AHU’s were manufactured using specialist thermal-break aluminium profile. Achieving a thermal bridging factor in excess of TB2(M) not only improves energy efficiency, but also minimises the risk of any condensation forming internally or externally, protecting the units from both corrosion and micro-organism growth.

To further improve the energy efficiency the recovery system, all supply and extract units serving the new Laboratories incorporated dual run-around coil systems comprising four multi-row finned tube coils connected via a pumped pipework circuit.
